Switch A Switch B
1 2
Data
Data
Data
Data
=IEC09000758=3=en=Original.vsd
IED
Configuration
PRP
PRPSTATUS
1 2
OEM
AB CD
Duo
Redundancy
Supervision
Station Control System
IEC09000758 V3 EN-US
Figure 198: Redundant station bus
18.2.6.3 Setting guidelines
GUID-6AD04F29-9B52-40E7-AA07-6D248EF99FC6 v2
Redundant communication (PRP) is configured in the local HMI under Main menu/
Configuration/Communication/Ethernet configuration/PRP
The settings are found in the Parameter Setting tool in PCM600 under IED Configuration/
Communication/Ethernet configuration/PRP. By default the settings are read only in the
Parameter Settings tool, but can be unlocked by right clicking the parameter and selecting
Lock/Unlock Parameter.
Operation
: The redundant communication will be activated when this parameter is set to
On.
After confirmation the IED will restart and the setting alternatives
Rear OEM - Port AB
and
CD
will not be further displayed in the local HMI. The
ETHLANAB
and
ETHLANCD
in the
Parameter Setting Tool are irrelevant when the redundant communication is activated, only
PRP IPAdress and IPMask are valid.
1MRK 511 358-UEN A Section 18
Station communication
409
Application manual
