ABB RER620

Section 4 1MAC309294-MB F
Protection functions
96 RER620
Technical Manual
Operating curve type 1=ANSI Ext Inv
2=ANSI Very Inv
3=ANSI Norm Inv
4=ANSI Mod Inv
5=ANSI DT
6=LT Ext Inv
7=LT Very Inv
8=LT Inv
9=IEC Norm Inv
10=IEC Very Inv
11=IEC Inv
12=IEC Ext Inv
13=IEC ST Inv
14=IEC LT Inv
15=IEC DT
17=Programmable
18=RI Type
19=RD Type
-1=Recloser 1 (102)
-2=Recloser 2 (135)
-3=Recloser 3 (140)
-4=Recloser 4 (106)
-5=Recloser 5 (114)
-6=Recloser 6 (136)
-7=Recloser 7 (152)
-8=Recloser 8 (113)
-9=Recloser 8+ (111)
-10=Recloser 8*
-11=Recloser 9 (131)
-12=Recloser 11 (141)
-13=Recloser 13 (142)
-14=Recloser 14 (119)
-15=Recloser 15 (112)
-16=Recloser 16 (139)
-17=Recloser 17 (103)
-18=Recloser 18 (151)
-19=Recloser A (101)
-20=Recloser B (117)
-21=Recloser C (133)
-22=Recloser D (116)
-23=Recloser E (132)
-24=Recloser F (163)
-25-Recloser G (121)
-26=Recloser H (122)
-27=Recloser J (164)
-28=Recloser Kg (165)
-29=Recloser Kp (162)
-30=Recloser L (107)
-31=Recloser M (118)
-32=Recloser N (104)
-33=Recloser P (115)
-34=Recloser R (105)
-35=Recloser T (161)
-36=Recloser V (137)
-37=Recloser W (138)
-38=Recloser Y (120)
-39=Recloser Z (134)
5=ANSI DT Selection of time delay curve type
Type of reset curve 1=Immediate
2=Def time reset
3=Inverse reset
1=Immediate Selection of reset curve type
Pickup block enable 0=Disabled
1=Enabled
0=Disabled Enables start block function
Pickup block value 1.00...40.00 A 0.01 5 Value over which trip will be blocked
Time adder 0.00...2.00 s 0.01 0 Time added after curve time before trip
Parameter Values (Range) Unit Step Default Description
