ABB RER620

Section 4 1MAC309294-MB F
Protection functions
248 RER620
Technical Manual
4.5.2.6 Settings
Table 258: 50BFC Non group settings RA01
Table 259: 50BFC Non group settings RA02
4.5.2.7 Monitored data
Table 260: 50BFC Monitored data
4.5.2.8 Technical data
Table 261: 50BFC Technical data
4.5.3 High impedance fault detector HIZ
4.5.3.1 Identification
Parameter Values (Range) Unit Step Default Description
Operation 1=Enable
5=Disable
5=Disable Operation Off / On
Close delay time 0...60000 ms 10 300 Delay timer for reclose attempt
Close pulse time 0...60000 ms 10 150 Pulse length of reclose outputs
Parameter Values (Range) Unit Step Default Description
Operation 1=Enable
5=Disable
1=Enable Operation Off / On
Close delay time 0...60000 ms 10 2000 Delay timer for reclose attempt
Close pulse time 0...60000 ms 10 150 Pulse length of reclose outputs
Name Type Values (Range) Unit Description
50BFC Enum 1=enabled
2=blocked
3=test
4=test/blocked
5=disabled
Status
Characteristic Value
Time accuracy ±1.0% of the set value or ±20 ms
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
High impedance fault detector PHIZ HIF HIZ
