ABB RER620

Section 7 1MAC309294-MB F
Measurement functions
408 RER620
Technical Manual
7.1.10.5 Monitored data
Table 371: P,SP,E Monitored data
Name Type Values (Range) Unit Description
S-kVA FLOAT32 -999999.9...999999.9 kVA Total Apparent Power
P-kW FLOAT32 -999999.9...999999.9 kW Total Active Power
Q-kVAr FLOAT32 -999999.9...999999.9 kVAr Total Reactive Power
PF FLOAT32 -1.00...1.00 Average Power factor
SA-kVA FLOAT32 -999999.9...999999.9 kVA Phase A Apparent Power
SB-kVA FLOAT32 -999999.9...999999.9 kVA Phase B Apparent Power
SC-kVA FLOAT32 -999999.9...999999.9 kVA Phase C Apparent Power
PA-kW FLOAT32 -999999.9...999999.9 kW Phase A Active Power
PB-kW FLOAT32 -999999.9...999999.9 kW Phase B Active Power
PC-kW FLOAT32 -999999.9...999999.9 kW Phase C Active Power
QA-kVAr FLOAT32 -999999.9...999999.9 kVAr Phase A Reactive Power
QB-kVAr FLOAT32 -999999.9...999999.9 kVAr Phase B Reactive Power
QC-kVAr FLOAT32 -999999.9...999999.9 kVAr Phase C Reactive Power
PFA FLOAT32 -1.00...1.00 Phase A Power factor
PFB FLOAT32 -1.00...1.00 Phase B Power factor
PFC FLOAT32 -1.00...1.00 Phase C Power factor
S_INST FLOAT32 -999999.9...999999.9 kVA Apparent power, magnitude of
instantaneous value
S_DB FLOAT32 -999999.9...999999.9 kVA Apparent power, magnitude of reported
value
P_INST FLOAT32 -999999.9...999999.9 kW Active power, magnitude of
instantaneous value
P_DB FLOAT32 -999999.9...999999.9 kW Active power, magnitude of reported
value
Q_INST FLOAT32 -999999.9...999999.9 kVAr Reactive power, magnitude of
instantaneous value
Q_DB FLOAT32 -999999.9...999999.9 kVAr Reactive power, magnitude of reported
value
PF_INST FLOAT32 -1.00...1.00 Power factor, magnitude of
instantaneous value
PF_DB FLOAT32 -1.00...1.00 Power factor, magnitude of reported
value
EA_RV_ACM INT128 0...999999999 kWh Accumulated reverse active energy
value
ER_RV_ACM INT128 0...999999999 kVArh Accumulated reverse reactive energy
value
EA_FWD_ACM INT128 0...999999999 kWh Accumulated forward active energy
value
ER_FWD_ACM INT128 0...999999999 kVArh Accumulated forward reactive energy
value
SA_INST FLOAT32 -999999.9...999999.9 kVA Phase A Apparent power, magnitude of
instantaneous value
SA_DB FLOAT32 -999999.9...999999.9 kVA Phase A Apparent power, magnitude of
reported value
