4.1.3.9 Settings
Table 152: 51N/G, 50N/G-1 and 50SEF Group settings
Parameter Values (Range) Unit Step Default Description
Pickup value 0.010...5.000 xIn 0.005 0.500 Pickup value
Pickup value mult 0.8...10.0 0.1 1.0 Multiplier for scaling the pickup value
Time multiplier 0.05...15.00 0.05 1.00 Time multiplier in IEC/ANSI IDMT curves
Trip delay time 40...200000 ms 10 40 Trip delay time
Operating curve type 1=ANSI Ext Inv
2=ANSI Very Inv
3=ANSI Norm Inv
4=ANSI Mod Inv
5=ANSI DT
6=LT Ext Inv
7=LT Very Inv
8=LT Inv
9=IEC Norm Inv
10=IEC Very Inv
11=IEC Inv
12=IEC Ext Inv
13=IEC ST Inv
14=IEC LT Inv
15=IEC DT
17=Programmable
18=RI Type
19=RD Type
-1=Recloser 1 (102)
-2=Recloser 2 (135)
-3=Recloser 3 (140)
-4=Recloser 4 (106)
-5=Recloser 5 (114)
-6=Recloser 6 (136)
-7=Recloser 7 (152)
-8=Recloser 8 (113)
-9=Recloser 8+ (111)
-10=Recloser 8*
-11=Recloser 9 (131)
-12=Recloser 11 (141)
-13=Recloser 13 (142)
-14=Recloser 14 (119)
-15=Recloser 15 (112)
-16=Recloser 16 (139)
-17=Recloser 17 (103)
-18=Recloser 18 (151)
-19=Recloser A (101)
-20=Recloser B (117)
-21=Recloser C (133)
-22=Recloser D (116)
-23=Recloser E (132)
-24=Recloser F (163)
-25-Recloser G (121)
-26=Recloser H (122)
-27=Recloser J (164)
-28=Recloser Kg (165)
-29=Recloser Kp (162)
-30=Recloser L (107)
-31=Recloser M (118)
-32=Recloser N (104)
-33=Recloser P (115)
-34=Recloser R (105)
-35=Recloser T (161)
-36=Recloser V (137)
-37=Recloser W (138)
-38=Recloser Y (120)
-39=Recloser Z (134)
5=ANSI DT Selection of time delay curve type
