Section 8 1MAC309294-MB F
Recording functions
420 RER620
Technical Manual
8.1.5 Settings
Table 378: Non-group general settings for digital fault recorder
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1 1=on Digital fault recorder on/off
Record length 10...500 fundamental cycles 1 50 Size of the recording in fundamental cycles
Pre-trg length 0...100 % 1 50 Length of the recording preceding the triggering
Operation mode 1=Saturation
2=Overwrite
1
1
(1
Operation mode of the recorder
Exclusion time 0...1 000 000 ms 1 0 The time during which triggerings of same type
are ignored
Storage rate 32, 16, 8 samples per fundamental cycle 32 Storage rate of the waveform recording
Periodic trig time 0...604 800 s 10 0 Time between periodic triggerings
Stor. mode periodic 0=Waveform
1=Trend / cycle
1 0 Storage mode for periodic triggering
Stor. mode manual 0=Waveform
1=Trend / cycle
1 0 Storage mode for manual triggering
(1
The default setting for RA02 is “Overwrite”.
