Table 306: 25 output signals
5.3.7 Settings
Table 307: 25 group settings
Name Type Description
SYNC_INPRO BOOLEAN Synchronizing in progress
SYNC_OK BOOLEAN Systems in synchronism
CL_FAIL_AL BOOLEAN CB closing failed
CMD_FAIL_AL BOOLEAN CB closing request failed
LLDB BOOLEAN Live Line, Dead Bus
LLLB BOOLEAN Live Line, Live Bus
DLLB BOOLEAN Dead Line, Live Bus
DLDB BOOLEAN Dead Line, Dead Bus
Parameter Values (Range) Unit Step Default Description
Live dead mode -1=Off
1=Both Dead
2=Live L, Dead B
3=Dead L, Live B
4=Dead Bus, L Any
5=Dead L, Bus Any
6=One Live, Dead
7=Not Both Live
1=Both Dead Energizing check mode
Difference voltage 0.01...0.50 xVn 0.01 0.05 Maximum voltage difference limit
Difference frequency 0.001...0.100 xFn 0.001 0.001 Maximum frequency difference limit
Difference angle 5...90 deg 1 5 Maximum angle difference limit
