1MAC309294-MB F Section 7
Measurement functions
RER620 393
Technical Manual
7.1.4.4 Settings
Table 343: IA,IB,IC Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=Enable
5=Disable
1=Enable Operation Off / On
Measurement mode 1=RMS
2=DFT
2=DFT Selects used measurement mode
Num of phases 1=1 out of 3
2=2 out of 3
3=3 out of 3
1=1 out of 3 Number of phases required by limit supervision
Demand interval 0=1 minute
1=5 minutes
2=10 minutes
3=15 minutes
4=30 minutes
5=60 minutes
6=180 minutes
0=1 minute Time interval for demand calculation
A high high limit 0.00...40.00 xIn 1.40 High alarm current limit
A high limit 0.00...40.00 xIn 1.20 High warning current limit
A low limit 0.00...40.00 xIn 0.00 Low warning current limit
A low low limit 0.00...40.00 xIn 0.00 Low alarm current limit
A deadband 100...100000 2500 Deadband configuration value for integral calculation. (percentage of
difference between min and max as 0,001% s)
