4.5.5.6 Signals
Table 272: 32P input signals
Table 273: 32P measured values
Table 274: 32P output signals
4.5.5.7 Settings
Table 275: 32P group settings
Table 276: 32P non-group settings
Name Type Default Description
V1 REAL 0.0 Positive sequence voltage
I1 REAL 0.0 Positive sequence current
BLOCK BOOL FALSE Block signal for all binary outputs
Name Type Default Description
I1_AMPL REAL 0.0 Positive sequence current amplitude
I1_ANGL REAL 0.0 Positive sequence current phase angle
V1_AMPL REAL 0.0 Positive sequence voltage amplitude
V1_ANGL REAL 0.0 Positive sequence voltage phase angle
BLOCK BOOL FALSE Block signal for all binary outputs
Name Type Description
RELEASE BOOL Release signal if directional criteria is satisfied
Name Values (Range) Unit Step Default Description
Directional mode 1=Non-directional
2=Forward
3=Reverse
2=Forward, Power direction forward or reverse direction
Max forward angle 0 …90 Deg 1 88 Maximum phase angle in forward direction
Max reverse angle 0 …90 Deg 1 88 Maximum phase angle in reverse direction
Min forward angle 0…90 Deg 1 88 Minimum phase angle in forward direction
Min reverse angle 0 …90 Deg 1 88 Minimum phase angle in reverse direction
Characteristic angle -179…180 Deg 1 60 Characteristic angle
Release delay time 0...1000 ms 1 10 Release delay time for the directional criteria
Name Values (Range) Unit Step Default Description
Operation 0=Off
1=On
1=ON Operation Off / On
Reset delay time 0…60000 ms 1 20 Reset delay time
Min operate voltage 0.01…1.00 pu 0.01 0.3 Minimum operating voltage
Min operate current 0.005…1.00 pu 0.001 0.1 Minimum operating current
