ABB RER620

Section 4 1MAC309294-MB F
Protection functions
164 RER620
Technical Manual
Table 175: 67/50N-2 Output signals
4.1.4.11 Settings
Table 176: 67/51N and 67/50N-1 Group settings
Name Type Description
TRIP BOOLEAN Trip
PICKUP BOOLEAN Pickup
Parameter Values (Range) Unit Step Default Description
Pickup value 0.010...5.000 xIn 0.005 0.010 Pickup value
Pickup value mult 0.8...10.0 0.1 1.0 Multiplier for scaling the pickup value
Directional mode 1=Non-directional
2=Forward
3=Reverse
2=Forward Directional mode
Time multiplier 0.05...15.00 0.05 1.00 Time multiplier in IEC/ANSI IDMT curves
