ABB RER620

Section 5 1MAC309294-MB F
Control functions
336 RER620
Technical Manual
5.3.9 Technical data
Table 310: 25 technical data
5.4 Loop control (DLCM)
5.4.1 Identification
5.4.2 Function block
Figure 177: Function block
5.4.3 Functionality
The loop control functionality enables proper switching of recloser in order to sectionalize
the faulted section from the distribution system. The function can be operated in three
modes, based on the type of the recloser in the loop control scheme. The full scheme of
loop control typically consists of three types of recloser used in the loop control system
design. They are sectionalizer recloser, mid-point recloser and tie-point recloser. The
functionality of loop control function in different modes is clearly explained in the next
sections of the document.
Characteristic Value
Operation accuracy Depending on the frequency of the voltage
measured: f
n
±1 Hz
Voltage: ±3.0% of the set value or ±0.01 x V
n
Frequency: ±10 mHz
Phase angle: ±3°
Reset time < 50 ms
Reset ratio Typical 0.96
Operate time accuracy in definite time mode ±1.0% of the set value or ±20 ms
Functional description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Loop control DLCM DLCM DLCM
SWOTF
DLCM
S1_V_A
S1_V_B
S1_V_C
S2_V_B
S2_V_C
S2_V_A
S1_ENABLE
S2_ENABLE
BLOCK
S1_STATUS
S2_STATUS
LCM_TRIP
LCM_CLOSE
RESET_IN
S1_DISABLED
S2_DISABLED
RESET_OUT
SET_GROUP_CHANGE
