9.9.3 Signals
Table 417: TONGAPC Input signals
Table 418: TONGAPC Output signals
Name Type Default Description
IN1 BOOLEAN 0=False Input 1
IN2 BOOLEAN 0=False Input 2
IN3 BOOLEAN 0=False Input 3
IN4 BOOLEAN 0=False Input 4
IN5 BOOLEAN 0=False Input 5
IN6 BOOLEAN 0=False Input 6
IN7 BOOLEAN 0=False Input 7
IN8 BOOLEAN 0=False Input 8
Name Type Description
Q1 BOOLEAN Output 1
Q2 BOOLEAN Output 2
Q3 BOOLEAN Output 3
Q4 BOOLEAN Output 4
Q5 BOOLEAN Output 5
Q6 BOOLEAN Output 6
Q7 BOOLEAN Output 7
Q8 BOOLEAN Output 8
