Table 110: 50P-1/2 Output signals
Table 111: 50P-3 Output signals
4.1.1.9 Settings
Table 112: 51P & 50P-1 Group settings
Name Type Description
TRIP BOOLEAN Trip
PICKUP BOOLEAN Pickup
Name Type Description
TRIP BOOLEAN Trip
PICKUP BOOLEAN Pickup
Parameter Values (Range) Unit Step Default Description
Pickup value 0.05...5.00 xIn 0.01 1.00 Pickup value
Pickup value mult 0.8...10.0 0.1 1.0 Multiplier for scaling the pickup value
Time multiplier 0.05...15.00 0.05 1.00 Time multiplier in IEC/ANSI IDMT curves
Trip delay time 40...200000 ms 10 40 Trip delay time
