ABB RER620 Technical Manual

Section 4 1MAC309294-MB F
Protection functions
270 RER620
Technical Manual
Blocking logic
The binary input BLOCK can be used to block the function. The activation of the BLOCK
input deactivates RELEASE output and resets the Timer.
4.5.6.5 Application
The directional negative/zero sequence power protection (32N) function improves the
possibility to obtain selective function of the over-current protection in meshed networks.
The 32N function is used to block or release other over current protection function.
4.5.6.6 Signals
Table 281: 32N input signals
Table 282: 32N measured values
Table 283: 32N output signals
Name Type Default Description
V2 REAL 0.0 Negative sequence voltage
VG REAL 0.0 Measured residual voltage or Ground voltage
VN REAL 0.0 Calculated residual voltage or Neutral voltage
I2 REAL 0.0 Negative sequence current
IG REAL 0.0 Measured residual current or Ground current
IN REAL 0.0 Calculated residual current or Neutral current
RCA_CTL BOOL FALSE Relay characteristic angle control
BLOCK BOOL FALSE Block signal for all binary outputs
Name Type Default Description
IG_AMPL REAL 0.0 Measured residual current or Ground current amplitude
IG_ANGL REAL 0.0 Measured residual current or Ground current phase angle
IN_AMPL REAL 0.0 Calculated residual current or Neutral current amplitude
IN_ANGL REAL 0.0 Calculated residual current or Neutral current phase angle
VG_AMPL REAL 0.0 Measured residual voltage or Ground voltage amplitude
VG_ANGL REAL 0.0 Measured residual voltage or Ground voltage phase angle
VN_AMPL REAL 0.0 Calculated residual voltage or Neutral voltage amplitude
VN_ANGL REAL 0.0 Calculated residual voltage or Neutral voltage phase angle
I2_AMPL REAL 0.0 Negative sequence current amplitude
I2_ANGL REAL 0.0 Negative sequence current phase angle
V2_AMPL REAL 0.0 Negative sequence voltage amplitude
V2_ANGL REAL 0.0 Negative sequence voltage phase angle
BLOCK BOOL FALSE Block signal for all binary outputs
RCA_CTL BOOL FALSE Relay characteristic angle control
Name Type Description
RELEASE BOOL Release signal if directionality criteria is satisfied
