1MAC309294-MB F Section 5
Control functions
RER620 279
Technical Manual
Table 290: 52 Output signals
Name Type Description
SELECTED BOOLEAN Object selected
EXE_OP_3P BOOLEAN Executes the command for open direction
EXE_CL_3P BOOLEAN Executes the command for close direction
OKPOS BOOLEAN Apparatus position is ok
OPEN_ENAD BOOLEAN Opening is enabled based on the input status
CLOSE_ENAD BOOLEAN Closing is enabled based on the input status
SELECTED_PH_A BOOLEAN Phase A object selected
SELECTED_PH_B BOOLEAN Phase B object selected
SELECTED_PH_C BOOLEAN Phase C object selected
EXE_OP_A BOOLEAN Executes the command for phase A open direction
EXE_OP_B BOOLEAN Executes the command for phase B open direction
EXE_OP_C BOOLEAN Executes the command for phase C open direction
EXE_CL_A BOOLEAN Executes the command for phase A close direction
EXE_CL_B BOOLEAN Executes the command for phase B close direction
EXE_CL_C BOOLEAN Executes the command for phase C close direction
OPENPOS_A BOOLEAN Apparatus phase A open position
OPENPOS_B BOOLEAN Apparatus phase B open position
OPENPOS_C BOOLEAN Apparatus phase C open position
CLOSEPOS_A BOOLEAN Apparatus phase A close position
CLOSEPOS_B BOOLEAN Apparatus phase B close position
CLOSEPOS_C BOOLEAN Apparatus phase C close position
OKPOS_A BOOLEAN Apparatus phase A position is ok
OKPOS_B BOOLEAN Apparatus phase B position is ok
OKPOS_C BOOLEAN Apparatus phase C position is ok
OPEN_ENAD_PH_A BOOLEAN Opening phase A is enabled based on input status
OPEN_ENAD_PH_B BOOLEAN Opening phase B is enabled based on input status
OPEN_ENAD_PH_C BOOLEAN Opening phase C is enabled based on input status
CLOSE_ENAD_PH_A BOOLEAN Closing phase A is enabled based on input status
CLOSE_ENAD_PH_B BOOLEAN Closing phase B is enabled based on input status
CLOSE_ENAD_PH_C BOOLEAN Closing phase C is enabled based on input status
