Table 7: ground voltage: Non group settings
Table 8: Alarm LED: Input signals
Table 9: Alarm LED: Non group settings
Parameter Values (Range) Unit Step Default Description
Secondary voltage 1=100V
2=110V
3=115V
4=120V
1=100V Secondary voltage
Primary voltage 0.001...440.000 kV 0.001 11.547 Primary voltage
Amplitude corr. 0.900...1.100 0.001 1.000 Amplitude correction
Name Type Default Description
Alarm LED 1 BOOLEAN 0=False Status of Alarm LED 1
Alarm LED 2 BOOLEAN 0=False Status of Alarm LED 2
Alarm LED 3 BOOLEAN 0=False Status of Alarm LED 3
Alarm LED 4 BOOLEAN 0=False Status of Alarm LED 4
Alarm LED 5 BOOLEAN 0=False Status of Alarm LED 5
Alarm LED 6 BOOLEAN 0=False Status of Alarm LED 6
Alarm LED 7 BOOLEAN 0=False Status of Alarm LED 7
Alarm LED 8 BOOLEAN 0=False Status of Alarm LED 8
Alarm LED 9 BOOLEAN 0=False Status of Alarm LED 9
Alarm LED 10 BOOLEAN 0=False Status of Alarm LED 10
Alarm LED 11 BOOLEAN 0=False Status of Alarm LED 11
Parameter Values (Range) Unit Step Default Description
Alarm LED mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for LED 1
Description Alarm LEDs LED 1 Description of alarm
Alarm LED mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for LED 2
Description Alarm LEDs LED 2 Description of alarm
Alarm LED mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for LED 3
Description Alarm LEDs LED 3 Description of alarm
Alarm LED mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for LED 4
Description Alarm LEDs LED 4 Description of alarm
Alarm LED mode 0=Follow-S
1=Follow-F
2=Latched-S
3=LatchedAck-F-S
0=Follow-S Alarm mode for LED 5
Description Alarm LEDs LED 5 Description of alarm
