1MAC309294-MB F Section 3
Basic functions
RER620 39
Technical Manual
Table 19: PG&E 2179 Protocol settings
Table 20: COM1/COM2 serial communication: Non group settings
Table 21: Serial communication: Non group settings
Parameter
Values
(Range)
Unit Step Default Description
Serial port 1 0=Not in use
1=COM 1
2=COM 2
0=Not in use COM port for Serial interface 1
End delay 1 0...20 char 4 End frame delay in chars on Serial interface 1
Device
Address 1
1...65535 1 1 PG&E Protocol unit address on Serial interface 1
Selection
Timeout
1...65 Sec 1 5 Selection Timeout for control SBO operation
Parameter Values (Range) Unit Step Default Description
Fiber mode 0=No fiber
1=Fiber light ON loop
2=Fiber light OFF loop
3=Fiber light ON star
4=Fiber light OFF star
0=No fiber Fiber mode for COM1
Serial mode 1=RS485 2Wire
2=RS485 4Wire
3=RS232 no handshake
4=RS232 with handshake
1=RS485 2Wire Serial mode for COM1
CTS delay 0...60000 0 CTS delay for COM1
RTS delay 0...60000 0 RTS delay for COM1
Baud rate 1=300
2=600
3=1200
4=2400
5=4800
6=9600
7=19200
8=38400
9=57600
10=115200
6=9600 Baud rate for COM1
Parameter Values (Range) Unit Step Default Description
Fiber mode 0=No fiber
1=Fiber light ON loop
2=Fiber light OFF loop
3=Fiber light ON star
4=Fiber light OFF star
0=No fiber Fiber mode for COM2
Serial mode 1=RS485 2Wire
2=RS485 4Wire
3=RS232 no handshake
4=RS232 with handshake
1=RS485 2Wire Serial mode for COM2
CTS delay 0...60000 0 CTS delay for COM2
RTS delay 0...60000 0 RTS delay for COM2
