ABB RER620

1MAC309294-MB F Section 10
General function block features
RER620 481
Technical Manual
Recloser H (122) Point to point data
Recloser J (164) Point to point data
Recloser K-Ground (165) Point to point data
Recloser K-Phase (162) 11.9847 -0.000324 2.01174 0.688477
Recloser L (107) Point to point data
Recloser M (118) Point to point data
Recloser N (104) 0.285625 -0.071079 0.911551 0.464202
Recloser P (115) Point to point data
Recloser P (115) Point to point data
Recloser R (105) 0.001015 -0.13381 0.00227 0.998848
Recloser T (161) Point to point data
Recloser V (137) Point to point data
Recloser W (138) 15.4628 0.056438 1.6209 0.345703
Recloser Y (120) Point to point data
Recloser Z (134) Point to point data
Note: Trip time is accurate when the time multiplier range is 0.1 - 4.0 for all reclose curves.
Curve name A B C D
