1MAC309294-MB F Section 3
Basic functions
RER620 47
Technical Manual
Table 30: Internal fault indications and codes
Fault indication Fault code Additional information
Internal Fault
System error
2 An internal system error has occurred.
Internal Fault
File system error
7 A file system error has occurred.
Internal Fault
Test
8 Internal fault test activated manually by the user.
Internal Fault
SW watchdog error
10 Watchdog reset has occurred too many times within an hour.
Internal fault
Supply voltage break
11 The auxiliary supply voltage has dropped to the failure level.
Internal fault
Settings error
32 Settings error has occurred.
Internal Fault
SO-relay(s),X105
40 Faulty Signal Output relay(s) in card located in slot X105.
Internal Fault
SO-relay(s),X115
41 Faulty Signal Output relay(s) in card located in slot X115.
Internal Fault
SO-relay(s),X100
43 Faulty Signal Output relay(s) in card located in slot X100.
Internal Fault
SO-relay(s),X110
44 Faulty Signal Output relay(s) in card located in slot X110.
Internal Fault
SO-relay(s),X120
45 Faulty Signal Output relay(s) in card located in slot X120.
Internal Fault
SO-relay(s),X130
46 Faulty Signal Output relay(s) in card located in slot X130.
Internal Fault
PO-relay(s),X105
50 Faulty Power Output relay(s) in card located in slot X105.
Internal Fault
PO-relay(s),X115
51 Faulty Power Output relay(s) in card located in slot X115.
Internal Fault
PO-relay(s),X100
53 Faulty Power Output relay(s) in card located in slot X100.
Internal Fault
PO-relay(s),X110
54 Faulty Power Output relay(s) in card located in slot X110.
Internal Fault
PO-relay(s),X120
55 Faulty Power Output relay(s) in card located in slot X120.
Internal Fault
PO-relay(s),X130
56 Faulty Power Output relay(s) in card located in slot X130.
Internal Fault
Light sensor error
57 Faulty ARC light sensor input(s).
Internal Fault
Conf. error,X105
60 Card in slot X105 is wrong type.
Internal Fault
Conf. error,X115
61 Card in slot X115 is wrong type.
Internal Fault
Conf. error,X000
62 Card in slot X000 is wrong type.
Internal Fault
Conf. error,X100
63 Card in slot X100 is wrong type or does not belong to the
original composition.
Internal Fault
Conf. error,X110
64 Card in slot X110 is wrong type, is missing or does not belong
to the original composition.
Internal Fault
Conf. error,X120
65 Card in slot X120 is wrong type, is missing or does not belong
to the original composition.
