ABB RER620

1MAC309294-MB F Section 10
General function block features
RER620 525
Technical Manual
Table 424: Coefficients for ANSI delayed inverse reset curves
Curve name D
(1) ANSI Extremely Inverse 29.1
(2) ANSI Very Inverse 21.6
(3) ANSI Normal Inverse 0.46
(4) ANSI Moderately Inverse 4.85
(6) Long Time Extremely Inverse 30
(7) Long Time Very Inverse 13.46
(8) Long Time Inverse 4.6
