Table 31: Warning indications and codes
For further information on warning indications, see the operation manual.
Warning indication Warning code Additional information
Warning
Internal system warning
2 An internal system warning condition has occurred.
Warning
Time synch error
5 A time synch error warning condition has occurred.
Warning
Watchdog reset
10 A watchdog reset has occurred.
Warning
Power down det.
11 The auxiliary supply voltage has dropped too low.
Warning
IEC61850 error
20 Error when building the IEC 61850 data model.
Warning
Modbus error
21 Error in the Modbus communication.
Warning
DNP3 error
22 Error in the DNP3 communication.
Warning
Dataset error
24 Error in the Data set(s).
Warning
Report cont. error
25 Error in the Report control block(s).
Warning
GOOSE contr. error
26 Error in the GOOSE control block(s).
Warning
SCL config error
27 Error in the SCL configuration file or the file is
missing.
Warning
Logic error
28 Too many connections in the configuration.
Warning
SMT logic error
29 Error in the SMT connections.
Warning
GOOSE input error
30 Error in the GOOSE connections.
Warning
ACT error
31 ACT error
Warning
GOOSE Tx/Rx error
32 Error in GOOSE message transmitting or receiving.
Warning
AFL error
33 Error in AFL configuration
Warning
Unack card comp.
40 A new composition has not been
acknowledged/accepted.
Warning
Protection comm.
50 Error in protection communication.
Warning
UPD Voltage Low in X115
112 UPD Voltage Low in X115
Warning
UPS Communication error in X115
113 UPS Communication error in X115
Warning
UPS Command failure in X115
114 UPS Command failure in X115
Warning
Breaker Operation Failure
115 Breaker Operation Failure, possibly due to incorrect
setting for UPD or UPD profile setting.
