ABB RER620

Section 13 1MAC309294-MB F
Technical data
564 RER620
Technical Manual
Table 445: Uninterruptible Power Supply (UPS) tests
Table 446: Energizing inputs
Test Type test value Reference
Control voltage
(IEEE C37.90-2005)
• UPS0001
• UPS0002
90 to 150 V AC
180 to 280V AC
No influence
No influence
Control power interruptions
(IEC 60255-11-2008)
• UPS0001 and UPS0002 60 VDC 2 seconds (no battery)
IEEE C37.60 - 2003
• UPS0001 and UPS0002 15 kV, 27 kV, 38 kV reclosers No influence
Power consumption
(IEEE C37.90-2005)
• UPS0001
• UPS0002
90 to 150 VAC
180 to 280 VAC
25 W (nominal)/~120 W (max)
Auxiliary Power Supply 12 VDC & 24 VDC 20 W (nominal)/~24 W (max)
Battery Charger 48 VDC 35 W max
Battery Run Time 38 hr 48 VDC 12 amp hr. battery with standard
load (15 W)
Boost Supply Programmable 61-250 VDC 80 W max
Description Value
Rated frequency 50/60 Hz ± 5 Hz
Current inputs Rated current, I
n
0.2/1 A
1
1. Ordering option for ground current input
1/5 A
2
2. Ground current and/or phase current
Thermal withstand capability:
• Continuously 4 A 20 A
• For 1 s 100 A 500 A
Dynamic current withstand:
• Half-wave value 250 A 1250 A
Input impedance <100 mΩ <20 mΩ
Voltage inputs Rated voltage 100 V AC/ 110 V AC/ 115 V AC/ 120 V AC
(Parametrization)
Voltage withstand:
• Continuous 2 x V
n
(240 V)
• For 10 s 3 x V
n
(360 V)
Burden at rated voltage <0.05 VA
