ABB RER620

Section 3 1MAC309294-MB F
Basic functions
74 RER620
Technical Manual
Table 83: Cross reference between circuit breaker position and the output of the function block
Signals
Table 84: T_POS_CL Input signals
Table 85: T_POS_OP Input signals
Table 86: T_POS_OK Input signals
Table 87: T_POS_CL Output signals
Table 88: T_POS_OPOutput signals
Table 89: T_POS_OK Output signals
Settings
The function does not have any parameters available in LHMI or Protection and Control
Relay Manager (PCM600).
Circuit breaker position
Output of the function block
T_POS_CL T_POS_OP T_POS_OK
Intermediate '00' FALSE FALSE FALSE
Close '01' TRUE FALSE TRUE
Open '10' FALSE TRUE TRUE
Faulty '11' TRUE TRUE FALSE
Name Type Default Description
POS Double binary 0 Input signal
Name Type Default Description
CLK Double binary 0 Input signal
Name Type Default Description
CLK Double binary 0 Input signal
Name Type Description
CLOSE BOOLEAN Output signal
Name Type Description
OPEN BOOLEAN Output signal
Name Type Description
OK BOOLEAN Output signal
