ABB RER620

Section 4 1MAC309294-MB F
Protection functions
88 RER620
Technical Manual
Table 103: Timer characteristics supported by different stages
Operating curve type supported by 51P 50P-1 50P-2
(1) ANSI Extremely Inverse x x x
(2) ANSI Very Inverse x x
(3) ANSI Normal Inverse x x x
(4) ANSI Moderately Inverse x x
(5) ANSI Definite Time x x x
(6) Long Time Extremely Inverse x x
(7) Long Time Very Inverse x x
(8) Long Time Inverse x x
(9) IEC Normal Inverse x x x
(10) IEC Very Inverse x x x
(11) IEC Inverse x x
(12) IEC Extremely Inverse x x x
(13) IEC Short Time Inverse x x
(14) IEC Long Time Inverse x x
(15) IEC Definite Time x x x
(17) User programmable x x x
(18) RI type x x
(19) RD type x x
(-1) Recloser 1 (102) x x
(-2) Recloser 2 (135) x x
(-3) Recloser 3 (140) x x
(-4) Recloser 4 (106) x x
(-5) Recloser 5 (114) x x
(-6) Recloser 6 (136) x x
(-7) Recloser 7 (152) x x
(-8) Recloser 8 (113) x x
(-9) Recloser 8+ (111) x x
(-10) Recloser 8* x x
(-11) Recloser 9 (131) x x
(-12) Recloser 11 (141) x x
(-13) Recloser 13 (142) x x
(-14) Recloser 14 (119) x x
(-15) Recloser 15 (112) x x
(-16) Recloser 16 (139) x x
(-17) Recloser 17 (103) x x
(-18) Recloser 18 (151) x x
(-19) Recloser A (101) x x
(-20) Recloser B (117) x x
(-21) Recloser C (133) x x
(-22) Recloser D (116) x x
