ABB Welcome IP - 2.1.2 Installation boxes

Overview of product range
System Manual
│
17
2.1.2 Installation boxes
Overview of installation boxes
The installation boxes for surface mounting or flush-mounted installation are available
separately in the corresponding size for each device.
Notice
Installation boxes for surface mounting, flush mounting and pre-plastered
mounting are not included in the scope of delivery of an outdoor station and
must be purchased separately.
Abb. 4: Installation boxes for outdoor stations
Surface mounting
1 Installation boxes for surface mounting
■
Flush-mounted box for outdoor stations size 1/3, size 1/4, size 1/5, size 2/3
Flush mounting
2 Installation boxes for flush-mounted installation
■
Flush-mounted box for outdoor stations size 1/3, size 1/4, size 1/5, size 2/3
3 Pre-plastered mounting box
■
The pre-plastered mounting box serves as mounting accessory for plastering walls or
facades. The pre-plastered mounting box is installed prior to plastering. The pre-plastered
mounting box offers mounting points for the flush-mounted installation box.
■
Pre-plastered mounting box for outdoor stations size 1/3, size 1/4, size 1/5, size 2/3
1 2 3
