5.9.3 Installation boxes - Surface mounting
1 x 3
32
1 x 4
1 x 5 2 x 3
133
275
32
133
347
32
133
419
32
233
275
Fig. 39: Dimensions of surface-mounted installation boxes of outdoor stations (dimensions in mm)
211
40
1 x 3
71
283
40
1 x 4
71
2 x 3
211
140
171
355
40
1 x 5
71
Fig. 40: Boreholes of surface-mounted installation boxes of outdoor stations (dimensions in mm)
