Real Time Triplex Stand Alone DVR

CHAP 1. INTRODUCTION

10. TRI Button

• To convert to triplex function like 8 channel live display and 8 channel playback in the screen

simultaneously.

• Press the button first, you will have CH1 ~ CH 8 live displays and playbacks and press it again,

you will do other channels like CH9 ~ CH16 live displays and playbacks.

- When you press the button in live display mode, you will see 8 channel live displays and

8 channel playbacks with no video. To retrieve video from hard drive, press Playback button.

- When you press the button in playback mode, you will see 8 channel live displays and

8 channel playbacks that have selected.

11. INFO (information) Button / BACKUP Button

• To show system information of DVR

• During Playback mode, it works as USB / CD backup button

12. CD-Burner

• To burn CD for data back-up

13. Rewind (◀◀) Button

• It supports REW1, REW2, REW3 and REW4.

14. Play ( ▶) and Pause (II) Button

• To play and pause the recorded videos

15. Faster Forward (▶▶) Button

• It supports FF1, FF2, FF3, FF4 and FF5

16. Stop (■) Button

• To stop playback

17. Record Button

• To start and stop recording.

18. Search Button

• To access recordings from HDD

19. Enter Button

• To enter a selection

20. Menu Button

• To access System Setup Menu.
