Real Time Triplex Stand Alone DVR
18
Unscrew the sides, rear of the DVR and remove the top cover.
1. HDD Installation
CHAP 2. INSTALLATION
1
Install the HDDs on the HDD plate and screw as left.
2
3
Close the top cover and screw and turn on the power.
4
5
HDD Jumper Setting Information
Before install the Hard Disk Drives, please read the jumper setting
information on the label. If the jumper is not set properly,
the system will be disordered.
Check if HDD has no problem after HDD installation because
record function may not work well due to HDD problem.
It may reboot automatically when HDD has problems or it doesn’t
detect HDD.
Contact your local distributor and exchange with new one when
you find your HDD has a problem.
Make sure that the HDDs are set to “Master” & “Slave” properly
and then connect the power cable and IDE cable as left.
Fix HDDs to rack mount by screwing as left.
To Next Page
