Real Time Triplex Stand Alone DVR
17
7. Remote Controller
1. REC (Record)
2. Mute
3. CH1~CH10 (Channel selection)
4. MENU
5. INFO (Information)
6. Multi
7. PIP
8. AUTO
9 .Zoom ( 2 x digital zoom)
10 ◀ Left (CD Backup Start in Playback mode)
11 ▲ Up
12 ▶ Right (CD Backup Stop in Playback mode)
13 ▼ Down
14. ENTER
15. All (Search menu)
16. Time (Search by date/time)
17. List (Search by date/time list)
18 ■ Stop
19. REW (REW1, 2, 3 and 4)
20. FF (FF1, 2, 3, 4, and 5)
21 ▶Play
22. II Pause
23. P.B (Playback)
24. TRI (Triplex)
25. Panorama
26. P/T (Pan/Tilt)
27. Z/F (Zoom/Focus)
28. CD Backup
29. USB Backup
1. Open the battery
container by sliding
down the cover.
3. Close the container by
sliding up the cover.
2. Insert two batteries
according to
directions provided.
CHAP 1. INTRODUCTION
1
2
3
45
6
78
9
10
11
12
13
15
23 24
16 17
25
26
14
18
19
20
21
22
27
28
29
