Real Time Triplex Stand Alone DVR
59
1
1. If you press REC button, you will see REC in green on the right bottom of the screen. It means the DVR is
in the recording process.
- MA-REC : It records videos in Master HDD.
-SL-REC : It records videos in Slave HDD.
• To release REC function, press REC button again.
2. It indicates that playback function is on in live display mode, which is one of our main features,
that is simultaneous multi-function operation in one screen.
-MA-PLAY :It plays videos that have been stored in Master HDD.
-SL-PLAY :It plays videos that have been stored in Slave HDD.
You will know how to initiate Playback mode in following 2 sections, Search Mode and Triplex Function.
3. It means that audio function is set to channel 1.
CHAP 5. RECORDING MODE
2
3
