Accu-Chek ACTIVE User Manual

75
Checking your meter
7 Open a bottle of control solution.
8 Wipe the tip of the dropper with a clean, dry
paper towel to remove any dried-on residues.
9 Invert the bottle and hold it downwards at an
angle. Squeeze it gently until a small drop which
is free of any air bubbles is suspended from the
tip.
10 Apply one drop to the centre of the orange eld
without touching it with the tip of the dropper.
The eld must be completely covered with
solution.

Accu-Chek ACTIVE Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1 - 2 μL
Test Time	5 seconds
Memory Capacity	500 results
Display Type	LCD
Automatic Coding	Yes
Blood Sample	Capillary whole blood
Dimensions	97.8 x 46.8 x 19.1 mm
Battery Type	1 x 3V lithium battery (type CR2032)
Battery Life	Approximately 1000 tests
Data Transfer	Via infrared (IR) to computer
Operating Conditions	8-42°C, 10-85% RH
