www.accuenergy.com
V: 1.00 Revised: Jan 2021
40
AcuRev 2100 Series Power Meter: Web Manual
Chapter 7: Communications
The communication setting web page will allow the user to configure settings related to the
Ethernet networks and the Wireless network. The functions and protocols that the AcuRev
2100 supports can be congured by selecting the corresponding tab such as Emails, Time/Date,
Datalog, AcuCloud Post for communicating with the AcuCloud software, BACnet-IP, SNMP.
7.1 Network
The rst page the user will see after selecting the Communications option under the Settings
tab is the Network page. The network settings allow users to congure all network-related
settings including both Ethernet 1 and Ethernet 2 as well as WiFi.
7.1.1 Network Settings
The settings for the Ethernet 1 and Ethernet 2 are as follows:
• Ethernet 1 DHCP: Select 'Manual' to manually configure the IP address to access the
meter. If set to 'Manual', you'll also need to set the Subnet Mask and Gateway. By default,
the IP address for ETH1 will be 192.168.1.254. By default Ethernet port 1 is set to Manual.
Select “Auto” to have the meter assigned an IP address automatically. With this selection,
the Subnet Mask, and Gateway will also be automatically assigned.
NOTE: After changing DHCP to Auto, check the display of the meter (N02 NET Settings) to obtain the
new IP address that has been assigned. The new IP address will be displayed only after a module
reboot is performed and completed.
