AcuRev 2100 Series Power Meter: Web Manual
• SFTP Enable: To download the logged data from the module using an FTP client, select
Enable. The log le will then be available to be downloaded using an FTP client using the
following credentials:
Host: sftp://IPaddressofthemeter
Username: sftpuser
SFTP Password: accuenergy
Port: 22
By default the password for retrieving the backup log files is accuenergy. The user can
congure any password or can reset to the default of accuenergy by clicking on the "Reset
SFTP Password".
NOTE: After enabling the SFTP function the user must reboot the communication module in order
to access the data logs with the default password of 'accuenergy'.
Click 'Save' after changing any settings. Users will be prompted to reboot the AcuRev
2100 immediately or later. If later is chosen, the AcuRev 2100 must be rebooted from the
'Management' page in order for the changes to take eect.
7.5 Post Channel
The AcuRev 2100 supports the HTTP and FTP Post functions to send data from the meter to
an HTTP/FTP server. The AcuRev 2100 can post .csv les to three dierent HTTP or FTP servers
using HTTP Post or FTP Post.
In the case when there is no connection to the server, the AcuRev 2100 will store the posts and
send it out after the connection is restored. A maximum of 3000 les will be buered on the
module. The Clear Post Channel Logs button will allow users to clear the buered les on the
meter.
The AcuRev 2100 can post data to a server at intervals of time ranging from 1 minute to 1 month.
The settings for conguring the post channels to post the data can be found by clicking on
Settings and then selecting the Communications tab. Click Post Channels to congure any
of the three post channels.
