ACD MAX Series - MAX 200 Without Power Inverter Specs

MAX_Kurzanleitung_Brief_Overview_V1.03_de_en 102 / 105
General information
Available voltages
24 V DC and 230 V AC
Output power AC at 25 °C (W)
180 VA
Output power DC at 25 °C (W)
400 VA
Battery operating time (typical)
Approx. 8 hours at a load of 80 VA
Operating temperature
0 to 40 °C (humidity < 95%, not condensing)
Standards/safety
EN 60439-1/Section 8.3
32.4 MAX 200 without power inverter
Chassis
External dimensions
1135 x 550 x 592 mm (H x W x D)
Loading area
520 x 510 mm (W x D)
Loadbearing capacity
Max. total weight 150 kg/max. weight per shelf 30 kg
Weight (without additional
equipment)
Approx. 77 kg
Standards/safety
DIN 4554; GS-approval, certificate No. Z1A030619506 001 et.al.
General information
Available voltages
24 V DC
Output power AC at 25 °C (W)
400 VA
Operating temperature
0 to 40 °C (humidity < 95%, not condensing)
Standards/safety
EN 60439-1/Section 8.3
(The right to make technical modifications is reserved)
