25 Information on installed parts
25.1 Charger
The charger installed in this mobile workstation can be connected to any shockproof socket with a mains
voltage of 230 V AC – 50 Hz. If the battery tray is inserted and operating temperature has been reached,
charging starts immediately after connection to the mains.
Charger mains cable
For better accessibility, you can attach the mains cable for the internal charger to the top post on the right.
Alternatively, store it behind the rear panel.
Figure 10: Charger mains cable
Figure 11: Rear of MAX multifunction panel
Never allow the mobile workstations’ batteries to discharge to below the end-point voltage,
specifically not below 19 V.
A deep discharge protection feature is integrated in the mobile workstation which prevents this
deep discharging under normal operating conditions. The batteries should be recharged soon
after switching off by the deep discharge protection function to prevent further deep discharging
through self-discharging.
