MAX_Kurzanleitung_Brief_Overview_V1.03_de_en 72 / 105
26.2.1 Fixing the MAX powerstation
The changing station is designed to be fixed to a wall with three M8 x 60 mm screws. The station is
configured for the MAX cart in the factory.
Figure 16: MAX powerstation
Free-standing installation is also possible. In this case, it is fixed with two M8 x 60 mm screws on the four
feet. To do this, pierce the two prepared holes on the feet.
Figure 17: Fixing on the foot
26.2.2 Adjusting the MAX powerstation
If necessary, adjust the four levelling feet to balance out the height.
Front: 205 mm
Rear: 203 mm
