27.2 MAX 200 with power inverter
The MAX 200 is the entry version of the mobile workstation. Operate the MAX 200 as described in Section
24; for technical data, see Chapter 32.3.
Figure 23:MAX 200 with power inverter
27.3 MAX 200 without power inverter
The MAX 200 without power inverter provides only 24 V DC supply voltage. No 230 V AC consumers can be
connected to this mobile workstation; for technical data, see Chapter 32.4.
Please note the maximum power output of the MAX 200 with power inverter (at 25 °C)
of 230 V AC/180 VA!
Please note the maximum power output of the MAX 200 without power inverter (at 25 °C) of 24 V
DC/400 VA!
WARNING
WARNING
