Acer H7530D - Page 12

Condential
1-5
H7530/H7530D
Modes Resolution V.Frequency [Hz] H.Frequency [KHz]
(2) VGA Analog - Extended Wide timing
WXGA 1280x768 60 47.8
1280x768 75 60.3
1280x768 85 68.6
1280x720 60 44.8
1280x800 60 49.6
1440x900 60 59.9
WSXGA+ 1680x1050 60 65.3
1366x768 60 47.71
1920x1080(CEA 861) 60 67.50
1024x600 60 37.50
(3) VGA Analog -Component Signal
480i 720x480 59.94(29.97)
576i 720x576 50(25)
480p 720x480 59.94
576p 720x576 50
720p60 1280x720 60
720p50 1280x720 50
1080i30 1920x1080 60(30)
1080i25 1920x1080 50(25)
1080p60 1920x1080 60
1080p50 1920x1080 50
Compatibility modes (HDMI Digital )
Modes Resolution V.Frequency [Hz] H.Frequency [KHz]
(1) HDMI - PC Signal
VGA 640x480 60 31.5
640x480 72 37.9
640x480 75 37.5
640x480 85 43.3
720x400 70 31.5
720x400 85 37.9
SVGA 800x600 56 35.1
800x600 60 37.9
800x600 72 48.1
800x600 75 46.9
800x600 85 53.7
