Acer H7530D - Assemble Engine; Assemble Speaker and Front IR Sensor Board

H7530/H7530D Condential 2-34
2-37 Assemble Engine
Module
1. Screw 3 screws (as yellow circle) to
assemble the Engine Module.
2.Stick EMI Gasket (as green square).
2-38 Assemble Speaker and
Front IR Sensor Board
1. Screw 2 screws (as yellow circle) to
assemble the Front IR Board and IR
Cover on Front Cover.
