Acer H7530D - Disassemble Engine Module

H7530/H7530D Condential 2-13
2. Unscrew 2 screws (as yellow circle) to
disassemble the Front IR Board and IR
Cover from Front Cover.
2-12 Disassemble Engine
Module
1. Tear off EMI Gasket (as green square).
2. Unscrew 3 screws (as yellow circle) to
disassemble the Engine Module.
IR Sensor Board
IR Cover
