Appendix C
RS232 function command summary table
General command type (Projector "receives" commands�" commands� commands�
No Code (character� Function feature
1 OKOKOKOKOK Power On
2 * 0 IR 001 Power On
3 * 0 IR 002 Power Off
4 * 0 IR 004 Keystone
5 * 0 IR 006 Mute
6 * 0 IR 007 Freeze
7 * 0 IR 008 Menu
8 * 0 IR 009 Up
9 * 0 IR 010 Down
10 * 0 IR 011 Right
11 * 0 IR 012 Left
12 * 0 IR 014 Re-Sync
13 * 0 IR 015 Source Analog RGB for D-sub
14 * 0 IR 017 Source PbPr for D-sub
15 * 0 IR 018 Source S-Video
16 * 0 IR 019 Source Composite Video
17 * 0 IR 020 Source Component Video
18 * 0 IR 021 Aspect ratio 16:9
19 * 0 IR 022 Aspect ratio 4:3
20 * 0 IR 023 Volume +
21 * 0 IR 024 Volume –
22 * 0 IR 025 Brightness
23 * 0 IR 026 Contrast
24 * 0 IR 027 Color Temperature
25 * 0 IR 030 Hide
26 * 0 IR 031 Source
27 * 0 IR 032 Video: Color saturation adjustment
28 * 0 IR 033 Video: Hue adjustment
29 * 0 IR 034 Video: Sharpness adjustment
30 * 0 IR 035 Query Model name
31 * 0 IR 036 Query Native display resolution
32 * 0 IR 037 Query company name
