Acer H7530D - Disassemble Speaker and Front IR Sensor Board

H7530/H7530D Condential 2-12
2-11 Disassemble Speaker
and Front IR Sensor
Board
1. Unscrew 2 screws (as red circle) to1. Unscrew 2 screws (as red circle) to
disassemble the Speaker from Left
Cover.
2. Separate Front Cover, Right Cover and
Left Cover.
Right Cover
Left Cover
