H7530/H7530D Condential 2-37
2. Plug 1 connector (as yellow square).
3. Fasten 2 tenons (as green arrows point)
by using the tweezers.
4. Screw 2 screws (as red circle).
5. Plug 2 connectors (as green square).
6. Screw 1 hex screw (as green circle).
7. Screw 3 screws (as yellow circle).
To Next Page
