― 41 ―
Hold up only F-type connector to turn it clockwise
into the Accelerometer.
Accelerometer
TYPE 7812B
① ②
※Do try to turn only F-type connector without causing damage to the cable, not to turn
or pull the accordion portion or curl cable, which may leads failure or malfunction
brought about the breaking of wire.
③
④
Curl cable
Accordion portion
F-type Connector
2）How to connect/disconnect F-type connector of curl cable.
<Connection>
① Hold up Accelerometer and F-type connector of curl cable to fit each other.
② Hold up only F-type connector to turn it clockwise into the Accelerometer.
<Disconnection>
③④ Hold up the Accelerometer and turn F-type connector of curl cable counterclockwise
until they come free.
F40358-14
