Technical Details
© 2018 ACTIA I+ME GmbH │ Ref. IR:14938 15 / 92
4 Technical Details
BOP XD
Attributes
Values
Camera
Supply
12 VDC / max. 2A
Monitor
Connections
BNC/ 75 Ohm/ 1Vss/ FBAS/ PAL or NTSC
Microphone
Connections
12 VDC / max. 1.5A
Supply voltage
10-32 VDC
Max.
Current consumption
Active: 0,6A by 24VDC/ 1A by 12VDC
Standby: 0,5mA by 24 VDC/ 0,5mA by 12VDC
Dimensions
269 x 93,2 x 216,6mm W/H/D
Weight
~2.9 kg
Working temperature
-25° to 70°C
Storage temperature
-25° to 85°C
Atmospheric humidity
10% ….95% relative atmospheric humidity, non-
condensing
Vibrations
0,2G/ 5-150 Hz during operation
1,0G/ 5-150 Hz with the device turned off
Shock load
Shock load
1,5G/ Half sinus/ 11ms during operation
50G/ Half sinus/ 11ms with the device turned off
Recording format
MPEG4/ H.264
