Mounting and Installation
© 2018 ACTIA I+ME GmbH │ Ref. IR:14938 23 / 92
7.2.2 Installation without BOP XD system rack
There are four boreholes at the bottom with a diameter of 6 mm.
1 Bore holes as per the boring diagram
2 Secure the BOP xD with 4 M6 screws
3 Use clamping rings or toothed lock washers to secure the screws.
4 Tighten the screws by hand
7.2.3 Installation with system racks
On the back of the BOP xD there are insertion slots for the mounting rack flaps.
1 Secure the system rack as per the Installation Instructions.
2 Consider the mounting rack used
3 Push the BOP with its back first in the mounting rack
4 Bend the front side at 25-30° so that the insertion flaps fit into the insertion slots
5 Press BOP slightly downward
6 BOP must be horizontal
7 Secure BOP with 2 M6 screws to the mounting rack
WARNING - Physical injuries
Mounting the device
Mount the BOP xD properly, so that it
cannot fall down.
Before departure, check whether the BOP
xD is firmly fixed.
Should the BOP xD fall during an accident because it
hasn’t been properly fixed and if it causes physical inju-
ries, consult a physician immediately
