Mounting and Installation
© 2018 ACTIA I+ME GmbH │ Ref. IR:14938 25 / 92
Connection “Ignition”
 Ignition on plug 2 - PIN2
 Ground plug 2 - PIN3
7.3.4 Power Supply and Data Sources
The BOP xD requires the following power supply voltage:
 12 VDC – 24 VDC
 10A fuse (time-lag).
Optional: IBIS data line, GPS signal, CAN bus data line, Ethernet network cable for
the network connection with iCount and Ethernet switch.
