Relay 2: Recording active relay. Closed during recording. Open in pause mode.
Relay 3: BOP active relay. Closed when BOP is started. It is only open when BOP is
switched off. Relay
4: Error relay. Indicates an active error as per the settings in >General settings<
12.5.5.7 Automatic Relay Control
Using the automatic relay control, the relays can be switched after the determined
sequence. The entire sequence is repeated cyclically from left to right.
 oxy = Output no. x with signal status y
 t.. = display duration
Example of a sequence segment
 o31-t10
Relay 3 is energised for 10 seconds.
Example of a sequence
 o30-t10,o31-t10
Relay 3 is switched on and off in a 10 seconds cycle.
12.5.5.8 Alarm Output
If there is an alarm, it can be signalled over a relay.
 0 No alarm is signalled.
 1 .. 4 The indicated relay is toggled in the event of an alarm
12.5.5.9 Alarm Signalling
Alarm recording can be signalled via the “Recording active” Relay 2.
 0 Relay 2 “Recording active” is constantly toggled during data
recording regardless of whether standard data or alarm data is being
recorded.
