Web Interface
© 2018 ACTIA I+ME GmbH │ Ref. IR:14938 71 / 92
12.5.6.1 IP Address / Netmask in Front
Default IP address (192.168.72.200) and Netmask (255.255.0.0) for the Ethernet
interface in the front.
12.5.6.2 IP Address / Netmask in the Back
IP address and Netmask for the Ethernet interface in the back.
Per default, it is set after the 10.30.xx.yy schema, whereas xx represents the two
second last and yy the last two numbers of the BOP xD serial number
(SN:1030xxyy).
12.5.6.3 Name Server 1/ Name Server 2
NOTICE
Special network settings. Contact your administrator.
12.5.6.4 Broadcast Target Address
In the event of an alarm signal at digital input 6 (PIN 9 - plug 2 - 21 PIN), an alarm
message is sent to the IP address provided.
12.5.6.5 Alarm RX OFF / ON
An alarm signal can be sent to the BOP from an external unit via the Ethernet. BOP
xD reacts to this external alarm in the same way it reacts to a normal alarm. Using
this function, all BOP xD units in the same network can be put into alarm mode.
 0 = no alarm over the Ethernet possible
 1 = alarm over the Ethernet possible
