ADB Signature Series User Manual

Ferroresonant L-828/L-829 CCR Parts
 2009 ADB Airfield Solutions, Incorporated
96A0288T 7-5
All rights reserved Issued 9/04
Part Number
Description
Quantity
(6.6 A)
Quantity
(20 A)
Schematic
Referenced
Note
35A0605
Power Transformer, 50kW/20A
480V, Ferro
1
35A0604
Power Transformer, 70kW/20A
480V, Ferro
1
35A0528
Transformer, current sensing,
20 A to 66 mA
1
T5
35A0539
Transformer, 240/480 to 120/24 volt
0.5 A, 4, 7.5, 10 kW
1
1
T4
35A0546
Transformer, 240/480 to 120/24 volt
0.5 A, 15, 20, 30, 57, 70 kW
1
1
T4
35A0548
Transformer, current sensing, 6.6 A
to 66 mA, 4, 7.5, 10, 15, 20,
30 kW
1
T5
44A6397
IRMS-L1, PCB ASSEMBLY ACE II
1
1
IRMS
44A6326-10
Circuit Voltage Monitor Assembly
Standard, 6.6a
1
ACE/CVM
44A6326-11
Circuit Voltage Monitor Assembly,
Standard, 20A
1
ACE/CVM
44A6178
Rotary switch, 3-step
1
1
44A6178-5
Rotary switch, 5-step
1
1
44A6035-1
PCB assembly, URC II, 4,7.5, 10, 15,
20, 30, 50, 70 kW
1
1
URC II PCB
47A0061
Fuse block, 4, 7.5, 10, 15, 20, 30. 50,
70 kW
See note.
See note.
F5, F6
B
47A0069
Fuse, 25A, 250 V, time delay, 220-
240 V input, 4 kW
2
2
F1, F2
47A0070
Fuse, 45A, 250 V, time delay, 240 V
input, 7.5 kW
2
2
F1, F2
47A0071
Fuse, 60A, 250 V, time delay, 220-
240 V input, 10 kW
2
2
F1, F2
47A0072
Fuse, 60A, 250 V, time delay, 208
V input, 20 kW
2
2
F1, F2
47A0085
Fuse, 30 A, 600 V, 480 V input, 10
kW
2
2
F1, F2
47A0087
Fuse, 90 A, 600 V, 480 V input, 20
kW
2
2
F1, F2
47A0088
Fuse, 50 A, 600 V, 480 V input, 15
kW
2
2
F1, F2
47A0090
Fuse, 12 A, 800 V, 480 V input, 4
kW
2
2
F1, F2
47A0091
Fuse, 25 A, 600 V, 480 V input, 7.5,
kW
2
2
F1, F2
NOTE A: For SMR only.
NOTE B: Quantity is 1 for L-828, SMI, IRMS with 208-480 V input. Quantity is 2 for ACE and SMR with 208-480 V
input.
Continued on next page
L-828/L-829 CCR General
Assembly Parts List (contd.)
